Smart Switch Module Sensor Motion Detector Finger Hand Sweep Sensor DC 12V 24V 3A Maximum 36W Power Light Switches

Package Included:

1* Switch Module

Specifications:
Operating voltage:
Input: 12V 24V
output: 12V 24V
Output type: double output
Detection range: 5-10 CM
Detection principle: distance
Power load: 36 W
Delayed off time: none
Field of application: DC, constant pressure
Load current: 3A optional
Standby current: 10mA

Features:
The use of electrical appliances, such as small household appliances, KTV VOD system,
Automotive industrial application systems and other electrical devices wide range of guests can accept custom special features;
The sensitivity of the product can be customized, can penetrate plastic, acrylic, glass, ceramic, and other non-metallic medium, stable performance!

Instructions:
AC use: Need to apply reactive rectifier for it is DC, constant pressure.
During installation, make sure that the medium insulation and tactile surface are tightly coupled and fixed!
There shoule no gap! Installed and then power, wait 3 seconds after initialization, it may be normal operation!
