RF 433MHz Wireless Light Switch AC 100-240V Relay Receiver Mini Round Button Switch Remote Control for Home LED Lamp 10A

Receiver:

1) Working voltage: AC85-240V 60HZ/50HZ
2) Working frequency: 433MHZ
3) Power consumption in standby mode: <0.3W
4) Load power: <1100W
5) Receiving sensitivity: -108dBM
6) Working way:wireless control
7) Coding way: learning code
8) Modulation: ASK
9) Working temperature: -10*C~+70"C
10) Size: 47.4*42*22.8 (mm)

433MHZ wireless switch signals

How to get the signals?
Step 1: Press the learning button(on the Receiver) twice . Wait for 3 seconds;
Step 2: Press one button on the remote control. Wait for 3 seconds. Succeed.

How to clear the signals?
Only one step :Press the learning button(on the Receiver) 8 times.

Note:

The relay controller is RF Receivers, the wall switch is RF only. Wall switch itself cannot control lights on off. It needs to work with rf receiver together.
